MSI MPG Z390 Gaming Pro Carbon AC 9th Gen ATX Motherboard

Computer Components > Motherboard > MSI (INTEL)

MSI MPG Z390 Gaming Pro Carbon AC 9th Gen ATX Motherboard

Model: MSI MPG Z390 Gaming Pro Carbon AC
Supports 9th & 8th Gen Intel Processor LGA 1151 socket
Supports up to 4400(OC) MHz
Lightning Fast Game experience
AUDIO BOOST 4 with NAHIMIC 3

TK 19300

Brand:

msi

Product Details

Specification

Basic Information
Supported CPU	Supports 9th / 8th Gen Intel Core / Pentium Gold / Celeron processors for LGA 1151 socket
Chipset	Intel Z390 Chipset
Form Factor	9.6 in. x 12 in. (24.3 cm x 30.4 cm) ATX Form Factor
Expansion Slots
PCI	3 x PCIe 3.0 x16 slots (support x16/x0/x4, x8/x8/x4 modes) 3 x PCIe 3.0 x1 slots
M.2 Socket	2 x M.2 slot (Key M) Support up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
Memory
Type	Dual-Channel Architecture
Slots	4 x DDR4 memory slots
Supported Memory	Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP)
Maximum Memory	support up to 128GB
Graphics
Graphics	1 x HDMI port 1.4, supports a maximum resolution of 4096x2160@24Hz 1 x DisplayPort port 1.2, supports a maximum resolution of 4096X2304@60Hz Supports 2-Way NVIDIA SLI Technology Supports 3-Way AMD CrossFire Technology
Connector & Ports
HDMI	1 x HDMI port 1.4, supports a maximum resolution of 4096x2160@24Hz
Display Port (s)	1 x DisplayPort port 1.2, supports a maximum resolution of 4096X2304@60Hz
USB (s)	Intel Z390 Chipset 5x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-C and 3 Type-A ports on the back panel, 1 Type-C internal connector) 4x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
LAN Port (s)	1 x Intel I219-V Gigabit LAN controller
Supported Storage	Intel® Z390 Chipset 6 x SATA 6Gb/s ports 2 x M.2 slot (Key M)1 Support up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices Intel Optane Memory Ready
Audio	Realtek ALC1220P-VB2 Codec 7.1-Channel High Definition Audio Supports S/PDIF output
Internal I/O Ports	1 x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 1x 4-pin ATX 12V power connector 6x SATA 6Gb/s connectors 1x USB 3.1 Gen2 Type-C port 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin Water Pump connector 5x 4-pin system fan connectors 1x Serial port connector 1x Front panel audio connector 2x System panel connectors 1x Thunderbolt Add-on Card Connector 1x Chassis Intrusion connector 1x TPM module connector 2x 4-pin RGB LED connectors 1x 3-pin RAINBOW LED connector 1x 3-pin CORSAIR LED connector
Warranty Information
Manufacturing Warranty	03 years warranty
