MSI MEG Z490 ACE 10th Gen ATX Gaming Motherboard

Computer Components > Motherboard > MSI (INTEL)

MSI MEG Z490 ACE 10th Gen ATX Gaming Motherboard

Model: MSI MEG Z490 ACE
Supports 10th Gen Intel Processors for LGA 1200 socket
Extreme Power Design
Outstanding Cooling Solution
Baseplate and M.2 Shield Frozr

Available EMI Offer

TK 38800

~~TK 42300~~

Brand:

msi

Quantity

ADD TO CART

ORDER NOW

Product Details

Specification

Basic Information
Supported CPU	Supports 10th Gen Intel Core and Pentium Gold /Celeron processors for LGA 1200 socket
Chipset	Intel Z490 Chipset
Form Factor	12 in. x 9.6 in. (30.5 cm x 24.4 cm) ATX Form Factor
Expansion Slots
PCI	3x PCIe 3.0 16 slots (2 from CPU, 1 from PCH, support 16/0/4, 8/8/4) 2x PCIe x1 slots (from PCH)
M.2 Socket	M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices M2_3 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices
Memory
Type	Dual channel memory architecture
Slots	4 x DDR4 memory slots
Supported Memory	Supports 1R 2133/2666/2933 MHz 1DPC 1R Max speed up to 4800+ MHz 1DPC 2R Max speed up to 4266+ MHz 2DPC 1R Max speed up to 4400+ MHz 2DPC 2R Max speed up to 4000+ MHz
Maximum Memory	128GB
Graphics
Graphics	Supports 2-Way NVIDIA SLI Technology Supports 3-Way AMD CrossFire Technology
Connector & Ports
USB (s)	Intel Z490 Chipset 4x USB 3.2 Gen 2 10Gbps ports (3 Type-A ports on the back panel, 1 Type-C internal connector) 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports through the internal USB connector) 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) ASMedia 3241 chipset 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel
LAN Port (s)	1x Realtek 8125B 2.5G LAN controller 1x Intel I219V 1G LAN controller WIFI & BLUETOOTH Intel AX201 Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps WiFi 6 Pre-Certified Supports Bluetooth 5.1 , FIPS, FISMA The Wireless module is pre-install in the M2 (Key-E) slot
Supported Storage	Intel Z490 Chipset 6x SATA 6Gb/s ports 3x M.2 slots (Key M) M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices M2_2 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280 storage devices M2_3 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices Intel Optane Memory Ready Supports Intel Smart Response Technology for Intel Core processors
Audio	Realtek ALC1220 Codec + ESS SABRE9018Q2C combo DAC 7.1-Channel High Definition Audio Supports Optical S/PDIF output
Internal I/O Ports	1x 24-pin ATX main power connector 2x 8-pin ATX 12V power connectors 6x SATA 6Gb/s connectors 3x M.2 slots (M-Key) 1x USB 3.2 Gen 2 10Gbps Type-C port 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin water-pump connector 6x 4-pin system fan connectors 1x front panel audio connector 2x system panel connectors 1x Chassis Intrusion connector 1x slow mode jumper 1x power button 1x reset button 1x 4-pin RGB LED connector 2x 3-pin RAINBOW LED connectors 1x 3-pin CORSAIR LED connector 1x RTD3 connector 1x TBT connector
TPM (Trusted Platform Module )	N/A
Warranty Information
Manufacturing Warranty	03 years
