Asus TUF B365M-Plus Gaming LGA1151 9TH Gen Micro ATX Motherboard

Computer Components > Motherboard > ASUS (INTEL)

Asus TUF B365M-Plus Gaming LGA1151 9TH Gen Micro ATX Motherboard

Model: Asus TUF B365M-Plus Gaming
Intel 9th / 8th Gen Intel Core, Pentium Gold and Celeron Processors
Military-grade TUF Components
Intel Optane memory ready
Onboard M.2 Heatsink

Available EMI Offer

TK 11200

~~TK 11720~~

Brand:

Asus

Product Details

Specification

Basic Information
Supported CPU	Intel Socket 1151 9th / 8th Gen Intel® Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0
Chipset	Intel B365
BIOS	128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 My Favorites, Last Modified log, F6 Qfan Control, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
Form Factor	mATX Form Factor 9.6 inch x 9.5 inch ( 24.4 cm x 24.1 cm )
Expansion Slots
PCI	1 x PCIe 3.0 x16 (x16 mode) 1 x PCIe 3.0 x16 (max at x4 mode) 1 x PCIe 3.0/2.0 x1
M.2 Socket	1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
Memory
Type	Dual Channel Memory Architecture
Slots	4 x DIMM DDR4
Supported Memory	DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors
Maximum Memory	64GB
Graphics
Graphics	Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/DVI-D/DisplayPort ports Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider Supports AMD CrossFireX Technology Supports up to 3 displays simultaneously
Max Shared Memory	Maximum shared memory of 1024 MB (for iGPU exclusively)
Connector & Ports
HDMI	1 x HDMI resolution 4096 x 2160 @ 30 Hz
Display Port (s)	1 x DisplayPort 1.2 resolution 4096 x 2304 @ 60 Hz
DVI-D (s)	1 x DVI-D resolution 1920 x 1200 @ 60 Hz
USB (s)	Intel B365 Chipset : 6 x USB 3.1 Gen 1 port(s) (4 at back panel, blue, 2 at mid-board) Intel B365 Chipset : 6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board)
LAN Port (s)	Intel I219V, 1 x Gigabit LAN TUF LANGuard
Supported Storage	1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) 6 x SATA 6Gb/s port(s), gray Support Raid 0, 1, 5, 10 Intel Optane Memory Ready
Audio	Realtek ALC1200 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Front Panel Jack-retasking Audio Feature : - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
Internal I/O Ports	1 x Addressable RGB header 1 x Aura RGB Strip Header 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin, moss green) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices 1 x COM port(s) connector(s) 6 x SATA 6Gb/s connector(s) 1 x CPU Fan connector(s) 2 x Chassis Fan connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector
Warranty Information
Manufacturing Warranty	03 Years
