Product Details
Specification
Basic Information | ||
Supported CPU | Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
|
Chipset | Intel H410 | |
BIOS | 128 Mb Flash ROM, UEFI AMI BIOS | |
Form Factor | 6.7 inch x 6.7 inch ( 17.02 cm x 17.02 cm ) | |
Expansion Slots | ||
PCI | 1 x PCIe 3.0/2.0 x16 | |
M.2 Socket | 1 x M.2 Socket 3, with M Key, type 2260/2280 storage devices support (PCIE mode) | |
Memory | ||
Type | Dual Channel Memory Architecture | |
Slots | 2 x DIMM | |
Supported Memory | Supports 2666/2400/2133 MHz Non-ECC, Un-buffered Memory Supports Intel Extreme Memory Profile (XMP) OptiMem II |
|
Maximum Memory | 64GB | |
Graphics | ||
Graphics | Integrated Graphics Processor- Intel UHD Graphics support 1 x HDMI 1.4b 1 x D-Sub |
|
Connector & Ports | ||
HDMI | 1 x HDMI 1.4b | |
D-Sub (s) | 1 x D-Sub | |
USB (s) | Rear USB Port ( Total 4 ) 2 x USB 3.2 Gen 1 (up to 5Gbps) port(s)(2 x Type-A) 2 x USB 2.0 port(s)(2 x Type-A) Front USB Port ( Total 4 ) 2 x USB 3.2 Gen 1 (up to 5Gbps) port(s) 2 x USB 2.0 port(s) |
|
LAN Port (s) | Realtek RTL8111H, 1 x Gigabit LAN Controller(s), support LANGuard | |
Supported Storage | Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports Intel H410 Chipset : 1 x M.2 Socket 3, with M Key, type 2260/2280 storage devices support (PCIE mode) 4 x SATA 6Gb/s port(s) |
|
Audio | Realtek ALC887 7.1-Channel High Definition Audio CODEC - Supports : Jack-detection, up to 24-Bit/192kHz playback Audio Feature : - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors |
|
Internal I/O Ports | 1 x CPU Fan connector(s) (1 x 4 -pin) 1 x Chassis Fan connector(s) 1 x AIO_PUMP connector 1 x AAFP connector 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s) 1 x M.2 Socket 3 4 x SATA 6Gb/s connector(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x System panel(s) 1 x Clear CMOS jumper(s) 1 x COM port header 1 x Speaker connector |
|
TPM (Trusted Platform Module ) | 1 x SPI TPM header | |
Warranty Information | ||
Manufacturing Warranty | 03 Years |
